Product Name:

AD2916 Video Splitter

Description:

Introduction

AD2916 series

 video distributor can put a video input signal is divided into multiple video outputsignal, or a video input signal is divided into two visual

Output signal frequency. Using special video operational amplifier, video signalthrough the distribution at the same time, can achieve a certain degree of phase correction, in a

Extent to correct the phase distortion of video transmission line. Video Splitter isentertainment, audio-visual, video matching equipment monitoring system.

The single channel video distributor can be a video signal distribution for multi-channel video signal output, for multiple video equipment used at the same time,

Consistent signal format after each video signal distribution output bandwidth, peak to peak voltage and output impedance and input, for the other visual

Frequency processor.

◆ four channel video distributor, multi input video assigner reduce the quantity of each distributor, can reduce the volume of equipment, improve the system stability

Qualitative. Four channel video assigner channel video input distribution of each channel is two road and input the same video output, for the

The video processor.

◆ eight channel video distributor, multi input video assigner reduce the quantity of each distributor, can reduce the volume of equipment, improve the system stability

Qualitative. Eight channel video assigner channel video input distribution of each channel is two road and input the same video output, for the

The video processor.

◆ sixteen channel video distributor, to the video input signal is divided sixteencompletely separate into sixteen groups of three channel video output signal.

Device characteristics:

 video black and white, color compatible

 a video input signal is divided into multiple video output signal

The distribution of output with automatic phase correction

 video flat frequency response

 multiple devices can be cascaded

Device parameters:

Equipment type:

AD2916-32

Power supply:

6W/AC220V+-10%/50Hz

Video input:

16 Road

Video output:

16 Road

Video signal-to-noise ratio:

>60dB

Video bandwidth:

12MHz (-3dB)

Environmental temperature:

-10oC~55oC

Ambient humidity.

<=90%RH (no condensation)

Size and shape:

480 (L) *310 (W) *89 (H) mm
